Lathe Universal TYTAN 750 Vario CORMAK

Tytan 750 Vario lathe from CORMAK is a rigid, durable and accurate lathe for metalworking, equipped with a lead screw and a base Description Equipped with multiple useful features, such as 250/750 mm turning, smooth spindle speed adjustment adjustable with a potentiometer, LCD displayed spindle speed, threading capability, bed and guides inductively hardened and ground, change gears made of metal, lead screw in a cover - in accordance with the newest safety and EC regulations. Also features longitudinal feeds, strong 1.1 kW motor, follow and steady rests, 3-jaw 125 mm self-centering chuck and a base with drawers for tools or any different items. This lathe is compliant with all European regulations and standards. Technical data Swing over bed 250 mm Swing over support 150 mm Centres width 750 mm Bed width 135 mm Spindle bore 26 mm Spindle taper MK4 Spindle speed adjustment smooth Spindle speed 50–2250 rpm Metric threads (18) 0.2–3.5 mm/rev. Inch threads (21) 8–56 threads/inch Feeds 0.07–0.4 mm/rev. Cross support travel range 70 mm Transverse travel range 110 mm Longitudinal travel range 650 mm Tailstock quill diameter 30 mm Tailstock quill travel 60 mm Tailstock taper MK2 Chuck size 125 mm Spindle motor 1.1 kW / 230V Tool holder dimensions 12 x 12 mm Dimensions (LxWxH) 1350 x 560 x 1250 mm Weight 205 kg Equipment Change gears MK4, MK2 dead centres Set of jaws Set of hex keys Set of wrenches Chuck key Lubricator Screwdrivers Steady rest Follow rest
